MORGANA DigiFold Pro

Price: Call
The DigiFold Pro is an automatic creasing / folding machine designed specifically for the professional digital or litho printer who has a need to crease and fold digitally printed, heavy weight or cross-grained stock.
Call: 0902 886 117 - (028) 2253 2772 for advice and purchase.



One box Crease and Fold finishing machine



The Digifold Pro is the ideal product for folding heavier weight paper stock. Designed specifically for the professional digital or litho printer who has a need to crease and fold digitally printed, heavy weight or cross grained stock. As a stand alone paper folding and creasing machine it is easy to use, and has been one of Morgana’s best selling products since it was first introduced in 2001. As its name suggests the new DigiFold Pro incorporates the all new SmartScreen panel making it simpler to use and offering increased functionality for the user. In addition to this significant feature improvement, we have once again used state of the art technology to increase its speed. The productivity of the DigiFold Pro has been increased by a very creditable 20% and will now crease and fold at 6000 sheets per hour while retaining the accuracy demanded by users of previous DigiFold models.



UP TO 400gsm STOCKS
No chance to fold digital printed stocks with 400gsm without cracks if it has no perfect creasing treatment. MORNANA creasing shape fits to prevent surface cracks on digital print stocks and fold easily with no cracks.



CREASE AND FOLD IN ONE BOX
No need any more separate 2 machines, Folding machine and Creasing machine. The DIgiFold Pro combined into one box for those jobs and simultaneously linked crease and folding jobs.



EASY SETING AND OPERATION
Thanks to the simultaneous setting between crease and fold, easy to set up program onto smart touch screen and memorize data to have easy job changes without re-setting time.



ADJUSATBLE CREASING DEPTH AND SQUARE
Depending on application required easily adjust the depth of crease as well as square, which makes easy setting for any of print stocks and avoid cracks on surface.



HIGH SPEED CREASE & FOLDING JOBS
Processing speed is maximum 6,000 sheets/hours, which is enough processing speed for POD jobs on site and best matching for short run productions.



MORANA DigiFold is essential Item for professional crease and folding jobs for any of scenes such as Small Copy Shop, Print Shop, In-House, Print Center with small foot spaces,

Maximum sheet size 700mm x 385mm (900mm x 385mm with optional extension table)
Minimum sheet size 210mm x 140mm
Maximum paper thickness 0.4mm (approx 400 gsm)* including laminated material
Minimum paper thickness 0.11mm*
Maximum number of folds per sheet 2
Maximum number programmed applications Unlimited alpha numeric
Minimum repeat crease distance 40mm
Minimum repeat fold distance 70mm (depending on paper weight)
Minimum crease distance from lead edge 50mm
Minimum fold distance from lead edge 50mm (depending on paper weight)
Minimum crease distance from tail edge 50mm
Minimum fold distance from tail edge 50mm (depending on paper weight)
Minimum fold length 70mm
Speed per hour (A4 in half) 6000 sph
Dimensions L 2020mm x W 680mm x H 1265mm
Weight 190kgs
Power requirement 240v 50/60hz

Options

Narrow creasing blade, Large sheet extension table
